4,4 mm plastik optik tolali kabel
◇ Tolali yadro materiali: PMMA
◇ Qoplama materiali: Ftorli polimer
◇ Ko'ylagi: PE/PVX
◇ Optik tuzilma: qadam
Mahsulotni tanishtirish
Spetsifikatsiya
◇ Tolali yadro materiali: PMMA
◇ Qoplama materiali: Ftorli polimer
◇ Ko'ylagi: PE/PVX
◇ Optik tuzilma: qadam
◇ Raqamli diafragma: 0.5
◇ Asosiy refrektsiya ko'rsatkichi: 1.49
Xususiyatlari
◇ Yengil, egiluvchan, chayqalishga yuqori qarshilik va aniq bo'linish, chidamlilik
◇ Optimal tarmoqli kengligi, yuqori va barqaror uzatish tezligi
◇ Suv o'tkazmaydigan, namga chidamli, magnitga qarshi, magnit va momaqaldiroqsiz
◇ texnik xizmat ko'rsatishning arzonligi, kooper resurslarini tejash, energiyani tejash va atrof-muhitni muhofaza qilish
◇ Elektromagnit to'lqin nurlanishiga qarshi immunitet, shovqin ta'siri yo'q, buzilishlarga yaxshi qarshilik ko'rsatish qobiliyati
Birinchi marta pe ko'ylagi bilan qoplangan, PVX yoki boshqa ko'ylagi materiallari POFda ikkinchi ko'ylagi sifatida qoplanadi, siqilishga qarshi, cho'zishga qarshi, silliqlashga qarshi va qarishga qarshi ko'rsatkichlar, ishlash muddatini uzaytiradi, u amal qiladi. ko'p sohalarga. Kabelda qabul qilingan noyob tor ko'ylagi, uni qayta ishlash yoki ishlatish paytida egiluvchan bo'lish qiyin, shu bilan birga kichkina kurtkani yechib olish oson. Bizning plastik optik kabelimizning afzalligi kuchli uzatish tarmoqli kengligi, elektromagnit parazitlarga qarshi, barqaror va ishonchli signal uzatilishidir.
Model | Yadro (mm) | OD (mm) | Zaiflash (dB% 2fkm) | Kurtka Material | Metr / rulon （metr） | Harorat (daraja) |
TX-CC0500-1B | 0.5mm×1 | 1.0mm±0.15 | 250 dan kam yoki unga teng | Oʻt | 1500/5000 | -55~70 |
TX-CC0500-1B/1.25 | % 7b% 7b0}}.5mm×1 | 1,25 mm±0,15 | 250 dan kam yoki unga teng | Oʻt | 1500/5000 | -55~70 |
TX-CC% 7b{1}}B | 0.75mm×1 | 2,2 mm±0,07 | 200 dan kam yoki teng | Oʻt | 2500 | -55~70 |
TX-CC1000-1B/1.25 | 1.% 7b{1}}mm×1 | 1,25 mm±0,15 | 200 dan kam yoki teng | Oʻt | 1500/5000 | -55~70 |
TX-CC% 7b{1}}B | 1.% 7b{1}}mm×1 | 2,2 mm±0,07 | 200 dan kam yoki teng | Oʻt | 2500/5000 | -55~70 |
TX-CC% 7b{1}}A | 1.% 7b{1}}mm×1 | 2,2 mm±0,07 | 180 dan kam yoki unga teng | Oʻt | 2500/5000 | -55~70 |
TX-CC1500-1/3.0} | 1,5 mm × 1 | 3.0mm±0.1 | 240 dan kam yoki unga teng | PE/PVX | 700 | -55~70 |
TX-CC2000-1/3.8 | 2.% 7b{1}}mm×1 | 3,8 mm±{2}},1 | 240 dan kam yoki unga teng | PE/PVX | 350 | -55~70 |
TX-CC3000-1/4.5 | 3.% 7b{1}}mm×1 | 4,5 mm±{2}}.1 | 240 dan kam yoki unga teng | PE/PVX | 150 | -55~70 |
TX-CC3000-1/5.0} | 3.% 7b{1}}mm×1 | 5.0mm±0.1 | 240 dan kam yoki unga teng | PE/PVX | 150 | -55~70 |
TX-CC% 7b{1}}B | 1.% 7b{1}}mm×2 | 2,2/4,4 mm±0,1 | 200 dan kam yoki teng | Oʻt | 1250 | -55~70 |
TX-CC% 7b{1}}A | 1.% 7b{1}}mm×2 | 2,2/4,4 mm±0,1 | 180 dan kam yoki unga teng | Oʻt | 1250 | -55~70 |
TX-CC1000-2B/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 200 dan kam yoki teng | PE+PVX | 500 | -55~70 |
TX-CC1000-2A/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 180 dan kam yoki unga teng | PE+PVX | 500 | -55~70 |
TX-CC1000-2C/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 200 dan kam yoki teng | PE+PVX | 300 | -55~70 |
TX-CC1000-2B/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 180 dan kam yoki unga teng | PE+PVX | 300 | -55~70 |
TX-CC1000-2KB/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 200 dan kam yoki teng | +PVC% 2bkevlar | 300 | -55~70 |
TX-CC1000-2KA/6.0} | 1.% 7b{1}}mm×2 | 2,2/4,4/6.0mm | 180 dan kam yoki unga teng | +PVC% 2bkevlar | 300 | -55~70 |
TX-CC% 7b{1}}BV | 1.% 7b{1}}mm×1 | 2,2 mm±0,07 | 200 dan kam yoki teng | VW% 7b{0}% 7d | 2500 | -55~70 |
TX-CC% 7b{1}}AV | 1.% 7b{1}}mm×1 | 2,2 mm±0,07 | 180 dan kam yoki unga teng | VW% 7b{0}% 7d | 2500 | -55~70 |
TX-CC% 7b{1}}BV | 1.% 7b{1}}mm×2 | 4,4 mm±{2}}.1 | 200 dan kam yoki teng | VW% 7b{0}% 7d | 1250 | -55~70 |
TX-CC% 7b{1}}AV | 1.% 7b{1}}mm×2 | 4,4 mm±{2}}.1 | 180 dan kam yoki unga teng | VW% 7b{0}% 7d | 1250 | -55~70 |
TX-CC1000-1B/4.0} | 1.% 7b{1}}mm×1 | 4.0mm±0.1 | 200 dan kam yoki teng | PE+PVX | 1000 | -55~70 |
TX-CC1000-1B/5.0} | 1.% 7b{1}}mm×1 | 5.0mm±0.1 | 200 dan kam yoki teng | PE+PVX | 500 | -55~70 |
Yuk tashish
Ommaviy tovarlar dengiz, havo, temir yo'l orqali jo'natiladi Biz Shanxay portiga, Ningbo portiga yaqinmiz | kichikroq jo'natish / shoshilinch jo'natish xalqaro ekspress orqali Yuk oldindan to'langan yoki yig'ilgan |
